7.5W series, 12W series, 18W series, 24W series, 30W series, 40W series, 50.4W series, External Power Supplies Fixed wall-plug-in type

OUTPUT

voltagelDG

4.0-75V

7.6-13V

13.1-19V

19.1-30V

Current [Max.

4A

2.5A

1.8A

1.25A

Power(Max.)

21.2W

24W

24W

24W

Ripple&noise

5240mV

Voltage

±5%

Standby power<

0.1W

INPUT

Votage

100-240VAC

Frequency

50-60H2

Curent

0.7A Max.

ENVIRONMENT

Operation

0Cto+45℃

Storage Temp

20℃ to+80℃

Operation

10%-90%

5AFETY

Safety
cerificates

6236861558
cB,cULus,FCC,CE,Gs,UKCA,RCM,CC,PSE,Kc

Other

MTBF

50,000 hours at 80%load and 25℃

Dimensian

U5:76.8X48.0X31.0mm
EU:76.8X48.0X30.0mm
UK:76.8X50.0X37.0mm
AU:76.8X54.5×39.0mm

OUTPUT

VoltagelDC

4.0-7.9V

8.0-12.0V

Current(Max.)

1.5A

0.93A

Power(Max.)

7.5W

Ripple&noise

≤200 mv

voltage tolerance

±5%

Standby power

≤0.1W

INPUT

voltage Range

100-240VAC

Frequency Range

50-60Hz

current

0.3A Max

ENVIRONMENT

operation Temp.

0℃to+45°℃

Storage Temp.

-20℃to +80℃

Operation HUM

10%-90%

SAFETY

Safety cetficates

6236861558
CB,cULus,FCC,CE,GS,UKCA,RCM,CCC,PSE

Other

MTBF

>50,000 hours at 80%load and 25℃

Dimension(S)

US/EU:66.3X36.5X24.1mm
UK:66.3X36.5×49.5mm
AU:66.3×36.5X40mm

Dimension(W)

US/EU:60×39X26mm
UK:60X49.5X34mm
AU:60X39X35mm

OUTPUT

voftagelDC)

4.0-7.5V

7.6-13V

13.1-19V

19.1-30V

current (Max)

4A

2.5A

1.8A

0.94A

Power (Max.)

15W

18W

18W

18W

Ripple&noise

s240mV

Voltage

+5%

Standby power

0.1W

INPUT

voltago

100-240VAC

Frequency

50-60Hz

Current

0.5A Max.

ENV1RONMENT

operation Temp

octo+45℃

storage Temp

20℃ to +80C

Operation HUM

10%-90%

SAFETY

safety
certificates

6236861558
CB,cULus,FCC,CE,G5,UKCA,RCM,CC,PSE,KC

Other

MTBF

50,000 hours at 80%load and 25℃

pimension

us:76.8X48.0X31.0mm
Eu:76,8X48.0X30.0mm
UK:76.8X50.0X37.0mm
AU:76.8X54.5X390mm

OUTPUT

Voltage(DC)

5V

9V

12

Current(Max.)

3A

2A

1.5

Power(Max.)

15W

18W

18W

Ripple&noise

s150mV

Voltage

±5%

Standby power

<0.1W

INPUT

voltage

100-240VAC

Frequency

50-60Hz

Current

0.5A Max.

ENVIRONMENT

operation

octo+45℃

storage Temp.

20℃ to+80℃

operation HUM

10%-90%

SAFETY

Safety
cerificates

6236861558
CB,cULus,FCC,GS,UKCA,RCM,CCC,PSE

Other

MTBF

>50.000 hours at 80%load and 25℃

Dimension(S)

us/EU:67.5X45.5X34.5mm
EU:67.5X45.5X28.0mm
UK:66.0X49.0X34.5mm
AU:64.8X43.5×35.0mm

Dimension(W)

U5/EU:67.5X45.5X34.5mm
UK:66X49X34.5mm
AU:64.8X43.5X35mm

OUTPUT

Voltage(DC)

5-7.5V

76-11.9V

12-13V

13.1-19V

19.1-30V

Current (Max.

4A

3A

2.5A

2.29A

1.57A

Power(Max.)

24W

27W

30W

30W

30W

Ripple&noise

s300mv

Voitage tolerance

±5%

Standby power

<0.1W

INPUT

voltage

10D-240VAC

Frequency

50-60H2

Current

0.8A Max

ENVIRONMENT

operation Temp

0Cto+45℃

Storage Temp

20℃to +80℃

Operation HUM

10%-90%

SAFETY

Safety certificates

6236861558
CB.cULus,FCC.CE,GS,UKCA,RCM,CCC.PSE

Other

MTBF

>50,000 hours at 80%load and 25℃

Dimension

U5:76.8X48.0X31.0mm
EU:76.8X48.0X30.0mm
uK:76.8X50.0X37.0mm
AU:76.8X54.5X39.0mm

OUTPUT

Voltage(DC)

9V

9.1-14V

14.1-23V

23.1-30V

Current(Max.

5A

4.2A

3.36A

2.1A

Power(Max.

45W

50.4W

50.4W

50.4W

Ripple&noise

≤300 mv

Voitage

±5%

standby power

≤0.1W

≤0.21W

<0.21W

<0.21W

INPUT

Voltage

100-240VAC

Frequency

50-60Hz

Current

1.3A Max.

ENVIRONMENT

Operation

o℃to +45℃

storage Temp

20℃to +80℃

operation HUM

10%-90%

SAFETY

Satety
certificates

6236861558
CB,cULus.FCC,CE,GS,UKCA,RCM,CCC,PSE.KC

Other

MTBF

50,000 hours at 80%load and 25℃

Dimension

u5:84.0X52.5X32.0mm
EU:84X52.50X32.0mm
UK:84.0X52.5X38.5mm
AU:84.0×54.5X40.0mm

OUTPUT

voitage(DC)

4.5-6.5V

6.6-12V

12.1-16V

16.1-24V

Current (Max.)

2.1A

1.5A

0.8A

0.66A

Power (Max.)

12w

Ripple&noise

≤200mv

Voltage tolerance

±5%

Standby power

0.1W

INPUT

Voltage Range

100-240VAC

Frequency Range

50-60Hz

Current

0.35A Max,

ENVIRONMENT

operation Temp

oCto+45℃

Storage Temp.

-20℃ to+80℃

operation HUM

10%-90%

SAFETY

Safety certificates

6236861558
cB, cULus, FCC, CE, GS, UKCA, RCM, CC, PSE, KC, BSM1

Other

MTBF

>50,000 hours at 80%load and 25℃

Dimension(S)

us/EU:66.3×36.5X24.1mm
UK:66.3X36.5X49.5mm
AU:66.3X36.5×40mm

Dimension(W)

US/EU:67.5X45.5X34.5mm
UK:66X49X34.5mm
AU:64.8X43.5X35mm

OUTPUT

voltageDC

5V

12V

Current  (Max.)

2A

1A

Power(Max.)

12w

Ripple&noise

s150mV

Voltage tolerance

±5%

Standby power

0.1W

INPUT

Voltage Range

100-240VAC

Frequency Range

S0-60Hz

Current

0.35A Max.

ENVIRONMENT

Operation Temp

oCto +45℃

Storage  Temp.

20℃ to+80C

operation HUM

10%-90%

SAFETY

Safety certificates

6236861558
CB.cULus,FCC.CE,GS,UKCA,RCM,CC,PSE.KC.BSM

Other

MTBF

>50,000 hours at 80%load and 25℃

Dimension(S)

uS/EU:6.3X36.5X241mm
uK:66.3X36.5×49.5mm
AU:66.3X36.5X40mm

Dimension(W)

us/EU:67.5X45.5X34.5mm
UK:66X49X34.5mm
AU:64.8X43.5X35mm
