USB-C Chargers
USB-C Chargers
OUTPUT |
Voltage &Current |
5V 3A/9V 2.22A/12V 1.67A |
Power(Max.) |
20W |
|
Ripple&noise |
≤200 mV |
|
Voltage tolerance |
±5% |
|
Standby power |
<0.1W |
|
INPUT |
Voltage Range |
100-240VAC |
Frequency Range |
50-60Hz |
|
ENVIRONMENT |
Operation Temp. |
0℃ to +25℃ |
Storage Temp. |
-20℃ to +70℃ |
|
Operation HUM |
10%-90% |
|
SAFETY |
Safety certificates |
6236861558 |
OTHERS |
MTBF |
>50,000 hours at 80%load and 25℃ |
Dimension |
40X30X22mm |
OUTPUT |
Voltage &Current |
5V 3A/9V 3A/12V 2.5A/15V 2A |
Power(Max.) |
30W |
|
PPS |
3.3V-11V~2.7A |
|
Ripple&noise |
≤200 mV |
|
Voltage tolerance |
±5% |
|
Standby power |
<0.1W |
|
INPUT |
Voltage Range |
100-240VAC |
Frequency Range |
50-60Hz |
|
ENVIRONMENT |
Operation Temp. |
0℃ to +25℃ |
Storage Temp. |
-20℃ to +70℃ |
|
Operation HUM |
10%-90% |
|
SAFETY |
Safety certificates |
62368 |
OTHERS |
MTBF |
>50,000 hours at 80%load and 25℃ |
Dimension |
49*42.5*26mm |
OUTPUT |
Voltage &Current |
5V 3A/9V 3A/12V 2.5A/15V 2A |
Power(Max.) |
30W |
|
PPS |
3.3V-11V~2.7A |
|
Ripple&noise |
≤200 mV |
|
Voltage tolerance |
±5% |
|
Standby power |
<0.1W |
|
INPUT |
Voltage Range |
100-240VAC |
Frequency Range |
50-60Hz |
|
ENVIRONMENT |
Operation Temp. |
0℃ to +25℃ |
Storage Temp. |
-20℃ to+70℃ |
|
Operation HUM |
10%-90% |
|
SAFETY |
Safety certificates |
62368 |
OTHERS |
MTBF |
>50,000 hours at 80%load and 25℃ |
Dimension |
40*38*25mm |
